ENGINE ASSY II ПОГРУЗЧИКА HYUNDAI 35/40/45/50L-7A

2 клика - переход в карточку товара, 1 клик - выбор запчасти на схеме

Поз.	Кат. номер	Наименование	Кол.
1	YUCW-00034 S/N:	PISTON RING KIT ( STD )	-
2	YUCW-00035 S/N:	PISTON KIT	-
3	YUCW-00748 S/N:	CONNECTING ROD	-
4	YUCW-00749 S/N:	CONNECTING ROD BOLT	-
5	YUCW-00036 S/N:	BEARING KIT-CONN ROD	-
8	@ S/N:	CYLINDER BLOCK	-
10	YUCW-00037 S/N:	PLUG	-
11	YUCW-00038 S/N:	PIN	-
12	YUCW-00039 S/N:	LOCK PIN-CYLINDER HEAD	-
13	YUCW-00040 S/N:	PIN-DOWEL STRAIGHT	-
14	@ S/N:	PLUG-CORE HOLE	-
15	YUCW-00041 S/N:	BYPASS VALVE-OIL FILTER	-
16	YUCW-00042 S/N:	LOCK PIN-C/S SPROCKET	-
18	YUCW-00043 S/N:	CAMSHAFT	-
18	YUCW-00044 S/N:	CAMSHAFT	-
19	YUCW-00750 S/N:	TIMING CHAIN KIT	-
20	@ S/N:	GEAR	-
21	@ S/N:	GEAR	-
22	YUCW-00045 S/N:	BOLT-CAMSHAFT SPROCKET	-
23	YUCW-00046 S/N:	BOLT-CAMSHAFT RETAINER	-
24	YUCW-00047 S/N:	RETAINER-CAMSHAFT	-
25	YUCW-00048 S/N:	CAMSHAFT BEARING #4	-
26	YUCW-00049 S/N:	CAMSHAFT BEARING #2, 3	-
27	YUCW-00050 S/N:	CAMSHAFT BEARING #2, 3	-
28	YUCW-00048 S/N:	CAMSHAFT BEARING #4	-
31	YUCW-00751 S/N:	WATER PUMP GASKET	-
32	YUCW-00072 S/N:	BOLT-WATER PUMP	-
35	YUCW-00051 S/N:	WATER PUMP	-
36	YUCW-00052 S/N:	DRIVE SHAFT-OIL PUMP	-
37	YUCW-00053 S/N:	LOCK PIN-OIL PUMP	-
38	YUCW-00054 S/N:	RETAINER-DRIVE SHAFT	-
39	YUCW-00055 S/N:	OIL PUMP	-
40	YUCW-00056 S/N:	BOLT-OIL PUMP	-
41	YUCW-00057 S/N:	SCREEN-OIL PUMP	-
42	YUCW-00058 S/N:	PLUG-RELIEF VALVE	-
43	YUCW-00059 S/N:	RELIEF VALVE-OIL PRESSURE	-
44	YUCW-00752 S/N:	OIL PRESSURE RLF VALVE SPRING	-
45	YUCW-00073 S/N:	BOLT-OIL PUMP COVER	-
46	YUCW-00753 S/N:	OIL PRESSURE RLF VLV PIN	-
47	YUCW-00061 S/N:	COVER-OIL PUMP	-
48	YUCW-00062 S/N:	FITTING-OIL FILTER	-
49	YUCW-00063 S/N:	OIL FILTER	-
50	YUCW-00064 S/N:	RING GEAR	1
51	YUCW-00754 S/N:	PIN	-
53	YUCW-00755 S/N:	FLYWHEEL PIN	-
54	YUCW-00756 S/N:	CRANKSHAFT RR OIL SEAL	-
55	YUCW-00068 S/N:	CRANKSHAFT	-
56	YUCW-00757 S/N:	PIN	-
57	YUCW-00758 S/N:	ENGINE FRONT COVER GASKET	-
58	YUCW-00070 S/N:	BALANCER-CR/SHF,EXTERNAL	-
58	YUCW-00071 S/N:	BALANCER-CR/SHF	-
60	YUCW-00759 S/N:	ENGINE FRT COVER BOLT	-
61	YUCW-00760 S/N:	ENGINE FRONT COVER	-
62	YUCW-00074 S/N:	KEY-CR/SHF BALANCER	-
63	YUCW-00075 S/N:	CR/SHF BEARING KIT #1,2,3	-
64	YUCW-00076 S/N:	CR/SHF BEARING KIT #4	-
65	YUCW-00077 S/N:	CR/SHF BEARING CAP BOLT	-
66	@ S/N:	CR/SHF BEARING CAP	-
67	YUCW-00078 S/N:	GASKET-O/SEAL HSG	-
68	YUCW-00761 S/N:	STUD	-
69	YUCW-00080 S/N:	BOLT	-
71	YUCW-00762 S/N:	CR/SHF RR OIL SEAL HSG	-
72	@ S/N:	DEFLECTOR	-
73	YUCW-00763 S/N:	BOLT	-
74	YUCW-00764 S/N:	OIL PAN GASKET	-
76	YUCW-00765 S/N:	OIL PAN	-
77	YUCW-00766 S/N:	OIL PAN DRAIN PLUG SEAL	-
78	YUCW-00767 S/N:	OIL PAN DRAIN PLUG	-
79	YUCW-00191 S/N:	BOLT-OIL PAN	-
80	YUCW-00192 S/N:	NUT-OIL PAN	-
81	YUCW-00193 S/N:	STUD-OIL PAN	-
82	YUCW-00194 S/N:	PLUG-ENGINE BLOCK	-
83	YUCW-00768 S/N:	CR/SHF FRONT OIL SEAL	-
84	YUCW-00196 S/N:	RETAINER NUT-OL SEAL	-
86	YUCW-00197 S/N:	WASHER	-
88	YUCW-00198 S/N:	BOLT	-
89	@ S/N:	GEAR	-
90	YUCW-00199 S/N:	RETAINER-BALANCER SHAFT	-
91	YUCW-00200 S/N:	BALANCER	-
92	YUCW-00037 S/N:	PLUG	-
93	YUCW-00201 S/N:	BEARING KIT	-
94	YUCW-00029 S/N:	BOLT-VALVE LIFTER GUIDE	-
95	@ S/N:	GEAR	-
105	YUCW-00202 S/N:	GASKET-WATER PUMP COVER	-
107	YUCW-00769 S/N:	WATER PUMP COVER BOLT	-
108	YUCW-00938 S/N:	FLYWHEEL	-
109	YUCW-00204 S/N:	PLUG	-
113	YUCW-00205 S/N:	GROMMET	-
114	YUCW-00083 S/N:	BEARING	-
120	YUCW-00084 S/N:	BEARING	-
121	@ S/N:	PIN	-
126	@ S/N:	BOLT	-
127	YUCW-00770 S/N:	CR/SHF POSN SENSOR	-
128	YUCW-00085 S/N:	RING	-
131	YUCW-00771 S/N:	SHOE	-
132	YUCW-00029 S/N:	BOLT-VALVE LIFTER GUIDE	-
133	YUCW-00772 S/N:	BRACKET	-
134	YUCW-00739 S/N:	DIPSTICK GAUGE	-
N	@ S/N:	NOT SUPPLIED PARTS	-
N108	YUCW-00203 S/N:	FLYWHEEL	-
