STEERING AXLE ПОГРУЗЧИКА HYUNDAI 50/60/70D-7E ACE
2 клика - переход в карточку товара, 1 клик - выбор запчасти на схеме
Поз. | Кат. номер | Наименование | Кол. | Наличие | В запрос |
---|---|---|---|---|---|
1 |
81FQ-50016
50DE
S/N: 0340 - 0347
|
STEERING AXLE ASSY | - |
|
|
1 |
81FQ-50017
70DE
S/N: 2651 ~
|
STEERING AXLE ASSY | - |
|
|
1 |
81FQ-50015
70DE
S/N: ~ 2629
|
STEERING AXLE ASSY | - |
|
|
1 |
81FQ-50016
70DE
S/N: 2630 - 2650
|
STEERING AXLE ASSY | - |
|
|
1 |
81FQ-50017
60DE
S/N: 0032 ~
|
STEERING AXLE ASSY | - |
|
|
1 |
81FQ-50015
60DE
S/N: ~ 0031
|
STEERING AXLE ASSY | - |
|
|
1 |
81FQ-50017
50DE
S/N: 0348 ~
|
STEERING AXLE ASSY | - |
|
|
1 |
81FQ-50015
50DE
S/N: ~ 0339
|
STEERING AXLE ASSY | - |
|
|
1-1 |
81FQ-50104
70DE
S/N: 2630 - 2650
|
STEERING AXLE WA | - |
|
|
1-1 |
81FQ-50103
70DE
S/N: ~ 2629
|
STEERING AXLE WA | - |
|
|
1-1 |
81FQ-50105
60DE
S/N: 0032 ~
|
STEERING AXLE WA | - |
|
|
1-1 |
81FQ-50103
60DE
S/N: ~ 0031
|
STEERING AXLE WA | - |
|
|
1-1 |
81FQ-50105
50DE
S/N: 0348 ~
|
STEERING AXLE WA | - |
|
|
1-1 |
81FQ-50103
50DE
S/N: ~ 0339
|
STEERING AXLE WA | - |
|
|
1-1 |
81FQ-50105
70DE
S/N: 2651 ~
|
STEERING AXLE WA | - |
|
|
1-1 |
81FQ-50104
50DE
S/N: 0340 - 0347
|
STEERING AXLE WA | - |
|
|
1-10 |
81FC-51700
S/N: 0340 - 0347
|
SCREW-SET | 2 |
|
|
1-11 |
S205-201006
S/N: 0340 - 0347
|
NUT-HEX | 2 |
|
|
1-12 |
81FC-51010
S/N: 0340 - 0347
|
GASKET | 4 |
|
|
1-13 |
81FC-51020
S/N: 0340 - 0347
|
COVER | 4 |
|
|
1-14 |
S035-081526
S/N: 0340 - 0347
|
BOLT-W/WASHER | 24 |
|
|
1-15 |
S653-600008
S/N: 0340 - 0347
|
NIPPLE-GREASE | 4 |
|
|
1-16 |
85FF-50230
70DE
S/N: ~ 2629
|
BOLT-HEX | - |
|
|
1-16 |
85FF-50230
60DE
S/N: ~ 0031
|
BOLT-HEX | - |
|
|
1-16 |
85FF-50230
50DE
S/N: ~ 0339
|
BOLT-HEX | - |
|
|
1-17 |
S205-161006
70DE
S/N: ~ 2629
|
NUT-HEX | 2 |
|
|
1-17 |
S205-161006
60DE
S/N: ~ 0031
|
NUT-HEX | 2 |
|
|
1-17 |
S205-161006
50DE
S/N: ~ 0339
|
NUT-HEX | 2 |
|
|
1-18 |
81FQ-50300
S/N: ~ 0339
|
LINK | 2 |
|
|
1-19 |
81FC-51800
S/N: ~ 0339
|
BUSHING | 2 |
|
|
1-2 |
81F8-51011
70DE
S/N: 2630 ~
|
KNUCKLE | 2 |
|
|
1-2 |
81F8-51010
70DE
S/N: ~ 2629
|
KNUCKLE | 2 |
|
|
1-2 |
81F8-51011
60DE
S/N: 0032 ~
|
KNUCKLE | 2 |
|
|
1-2 |
81F8-51010
60DE
S/N: ~ 0031
|
KNUCKLE | 2 |
|
|
1-2 |
81F8-51011
50DE
S/N: 0340 ~
|
KNUCKLE | 2 |
|
|
1-2 |
81F8-51010
50DE
S/N: ~ 0339
|
KNUCKLE | 2 |
|
|
1-20 |
81F6-51050
S/N: ~ 0339
|
PIN-LINK | 4 |
|
|
1-21 |
81F6-51220
S/N: ~ 0339
|
WASHER-SPECIAL | 4 |
|
|
1-22 |
S461-500302
S/N: ~ 0339
|
PIN-SPLIT | 4 |
|
|
1-23 |
S651-060008
S/N: ~ 0339
|
NIPPLE-GREASE | 4 |
|
|
1-24 |
81FC-51030
S/N: ~ 0339
|
HUB | 2 |
|
|
1-25 |
81FC-51041
S/N: ~ 0339
|
HUB-BOLT | 16 |
|
|
1-26 |
81F8-52100
S/N: ~ 0339
|
BEARING-TAPER ROLLER | 2 |
|
|
1-27 |
81F2-8017
S/N: ~ 0339
|
BEARING-TAPER ROLLER | 2 |
|
|
1-28 |
81FC-51900
S/N: ~ 0339
|
SEAL-OIL | 2 |
|
|
1-29 |
81FC-52000
S/N: ~ 0339
|
WASHER | 2 |
|
|
1-3 |
81F8-52200
S/N: ~ 0339
|
BEARING-THRUST | 2 |
|
|
1-30 |
81FC-52100
S/N: ~ 0339
|
NUT-SLOTTED | 2 |
|
|
1-31 |
S461-630652
S/N: ~ 0339
|
PIN-SPLIT | - |
|
|
1-32 |
81F8-51070
S/N: ~ 0339
|
CAP-HUB | - |
|
|
1-32 |
81F8-51070
S/N: ~ 0339
|
CAP-HUB | - |
|
|
1-33 |
@
SEE 3B50
S/N: ~ 0339
|
STEERING CYLINDER | - |
|
|
1-35 |
S017-200656
S/N: ~ 0339
|
BOLT-HEX | 4 |
|
|
1-36 |
S441-200006
S/N: ~ 0339
|
WASHER-HARDENED | 4 |
|
|
1-36 |
S441-200006
S/N: ~ 0339
|
WASHER-HARDENED | 4 |
|
|
1-38 |
81FQ-50400
S/N: ~ 0339
|
SUPPORT | 2 |
|
|
1-39 |
F14103600
S/N: ~ 0339
|
BUSHING | 2 |
|
|
1-4 |
81F8-52000
S/N: ~ 0339
|
BEARING-NEEDLE | 4 |
|
|
1-41 |
81FQ-50140
S/N: ~ 0339
|
BOOT-STEERING CYL | 2 |
|
|
1-42 |
S520-100000
S/N: ~ 0339
|
CLAMP-HOSE | 2 |
|
|
1-5 |
81FC-51401
70DE
S/N: 2639 ~
|
OIL SEAL | 2 |
|
|
1-5 |
81FC-51400
70DE
S/N: ~ 2638
|
OIL SEAL | 4 |
|
|
1-5 |
81FC-51401
60DE
S/N: 0032 ~
|
OIL SEAL | 2 |
|
|
1-5 |
81FC-51400
60DE
S/N: ~ 0031
|
OIL SEAL | 4 |
|
|
1-5 |
81FC-51401
50DE
S/N: 0340 ~
|
OIL SEAL | 2 |
|
|
1-5 |
81FC-51400
50DE
S/N: ~ 0339
|
OIL SEAL | 4 |
|
|
1-6 |
85FF-50200
S/N: ~ 0339
|
PIN-KING | 2 |
|
|
1-7 |
81FC-51520
S/N: ~ 0339
|
WASHER-THRUST | 2 |
|
|
1-8 |
81FC-51610
S/N: ~ 0339
|
SHIM WASHER(0.1T) | 2 |
|
|
1-9 |
81FC-51620
S/N: ~ 0339
|
SHIM WASHER(0.2T) | 2 |
|
|
2 |
Q101309001
S/N: ~ 0339
|
SHIM(1.0T) | 2 |
|
|
3 |
Q101309002
S/N: ~ 0339
|
SHIM(0.5T) | 2 |
|
|
4 |
S017-18060D
S/N: ~ 0339
|
BOLT-HEX | 8 |
|
|
5 |
S441-180006
S/N: ~ 0339
|
WASHER-HARDENED | 8 |
|
|
6 |
81FC-51050
S/N: ~ 0339
|
HUB NUT,M22X1.5 | 16 |
|
|
7 |
81FQ-50020
S/N: ~ 0339
|
PIPE ASSY-FRONT | 1 |
|
|
8 |
81FQ-50030
S/N: ~ 0339
|
PIPE ASSY-REAR | 1 |
|
|
9 |
S651-810008
S/N: ~ 0339
|
NIPPLE-GREASE | 2 |
|
|
